Option & Equipment
BATTERIES HEAVY-DUTY DUAL 1300 COLD-CRANKING AMPS includes battery box mounted to left side under cab
DARK ASH SEATS WITH JET BLACK INTERIOR ACCENTS VINYL SEAT TRIM
WHEELS 19.5" X 6.75" STEEL BLACK PAINTED 8-HOLES HUB PILOTED (STD)
GLASS DEEP-TINTED
ASSIST STEPS ALUMINUM
MIRRORS OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL TRAILERING UPPER GLASS MANUAL-FOLDING AND EXTENDING BLACK. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
SKID PLATE STEEL FRAME-MOUNTED PROTECTS THE TRANSFER CASE FROM THE GROUND
AUDIO SYSTEM 4.2" DIAGONAL COLOR DISPLAY AM/FM stereo with USB port and auxiliary jack (STD)
SUMMIT WHITE
PAINT SCHEME STYLE 1
GVWR 19 500 LB. (8845 KG)
GRILLE CHROME
ENGINE BLOCK HEATER
BUMPER FRONT CHROME
TIRES REAR 225/70R19.5G TRACTION BLACKWALL GOODYEAR Max Axle Load: 15 000 lb.
POWER TAKE OFF ENGINE CONTROL PROVISIONS Access is available on left-hand and right-hand side
LICENSE PLATE KIT FRONT
POWER OUTLET 110-VOLT AC
REMOTE KEYLESS ENTRY
WORK TRUCK PREFERRED EQUIPMENT GROUP includes standard equipment
SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
PROVISION FOR CAB ROOF-MOUNTED LAMP/BEACON provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
BATTERY TOP POST THREADED BATTERY JUMP START STUD (located on battery box)
REAR SUSPENSION 13 500 LB. (6 123 KG) MULTI-LEAF VARI-RATE
WINDOWS POWER WITH DRIVER EXPRESS UP AND DOWN AND EXPRESS DOWN ON ALL OTHER WINDOWS
WHEELBASE 165" (419.1 CM) 84" CA (STD)
SPARE TIRE DELETE (STD)
REAR AXLE 13 500 LB. (6 124 KG) DANA SPICER S14-110 SINGLE REDUCTION
ALTERNATOR 220 AMPS
WIRING HARNESS ACCESSORY FOR 9L7 WIRING TO JUNCTION BLOCK Includes connector and blunt cut wires
REAR AXLE 4.30 RATIO Max road speed: 75 MPH
AUXILIARY HARNESS 3' FOR HEADLAMPS AND TURN SIGNALS
HORN DUAL-NOTE
26 000 LB. GCWR (11 793 KG)
PAINT SOLID
SHOCK ABSORBERS REAR
TIRES FRONT 225/70R19.5G TRACTION BLACKWALL GOODYEAR Max Axle Load: 7 940 lb.
SNOW PLOW PREP PACKAGE includes (UNL) auxiliary harness for headlamps and turn signals (KW5) 220-amp alternator forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
ELECTRICAL PROVISIONS REAR OF FRAME UPFITTER BODY BUILDER WIRING includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
RECOVERY HOOKS FRONT FRAME-MOUNTED BLACK
FRONT AXLE 7 500 LB. DANA SPICER 60-256 SINGLE-REDUCTION FRONT DRIVING
DPF DIESEL PARTICULATE FILTER MANUAL REGENERATION customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
AXLE LIMITED SLIP DANA SPICER TRUETRAC TORQUE PROPORTIONING LIMITED SLIP
5500 HD SERIES
RUGGED DUTY SERVICE TRANSMISSION AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE ALLISON A1700RDS ratios: 3.10 1ST 1.80 2ND 1.40 3RD 1.00 4TH 0.70 5TH 0.61 6TH Rugged Duty Series
ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-DIESEL COMPATIBLE 350 hp @ 2500 rpm 750 lb.-ft. torque @ 1400 rpm (STD)
TAIL LAMP WIRING HARNESS PROVISIONS includes wiring for standard left and right taillamps separate 8 feet of extra cable wiring for left and right body-mounted tail lights
Turbocharged
Four Wheel Drive
Power Steering
ABS
Steel Wheels
Tires - Front All-Season
Tires - Rear All-Season
Running Boards/Side Steps
AM/FM Stereo
MP3 Capability
Auxiliary Audio Input
Split Bench Seat
Vinyl Seats
Adjustable Steering Wheel
Power Door Locks
Cruise Control
A/C
Traction Control
Stability Control
Daytime Running Lights
Automatic Headlights
Driver Air Bag
Passenger Air Bag
Passenger Air Bag On/Off Switch
Front Side Air Bag
Front Head Air Bag
Back-Up Camera
Backup Camera
